Manual stitching machine is a basic carton binding equipment, widely used in small and medium-sized carton packaging enterprises.

Structure and principle

- Main components: including nail head, support arm, drive motor, transmission clutch, machine body and foot switch, etc.

- Working principle: The drive motor transmits power through a single-stage or double-stage V-belt. When the operator steps on the foot switch, the transmission clutch starts and the nail head starts working.

Features

- Advantages: simple structure and affordable price.

Operation precautions

- Adjust the baffle: When nailing the box, adjust the position of the main baffle and the left and right baffles, as well as the position of the upper and lower nail heads according to the swing cover of the carton. The left and right baffles cannot be clamped too tightly.

- Machine lubrication: In daily maintenance, attention should be paid to regularly adding lubricating oil to keep the machine clean.
